Smart AHU

EC Fans

The EC-motor (EC = Electronically Commutated) is an inverter-fed synchronous motor with permanent magnets in external rotor construction.

Basically it is a fan MOTOR with a brushless DC motor. Basic DC motors rely on carbon brushes and a commutation ring to switch the current direction, and therefore the magnetic field polarity, in a rotating armature.

Installation Modes

• Retrofit- Replacement Of Old Fan With New EC Fans In Existing Ahu

• Entire New Ahu Installation With Ec Fans

What Value will these initiatives add?

• LEED & WELL points

• Energy Saving 30 %

• BSC ( British Safety Council ) start rating for building

• 50 % reduction in the occupied floor space compared to traditional AHU

• N + 1 in built redundancy

• Improved IAQ on account composite blower material

• Improved IAQ with 2 stage filtration ( MERV 8/13 )

• Feasibility of infusion of UV lights

• No VFD / Star Delta Starter / Single Phase prevention

• Remote diagnostic & self analytical troubleshoot program

• Increase IOT sensor coverage point & further integration with BMS

Features of Smart AHU

- Smart monitoring - extensive & accurate analysis , trends, MIS & MMR

- Tracking the status & criticality of alerts

- Common Wireless Sensor Device to monitor multiple parameters for all utility equipment

- Energy Management through optimization of fan and actuator valve operation in sync

- Time & Activity based alerts - Web, SMS & e-Mail

- Real-time dashboard for ease tracking on performance

- Data syncs with cloud server

- Common Module to monitor multiple parameters for all utility equipment

- Minimized or zero downtime of equipment

- Parameter web alert to ensure intense care on upkeep of facility
